Introduction of rubber conveyor belt and instructions on how to maintain the conveyor belt

Views: 0     Author: Site Editor     Publish Time: 2021-03-24      Origin: Site

Conveyor belt, rubber conveyor belt series products include cotton canvas belt, nylon (NN) belt (divided into NN-100 type, NN-150 type,

NN-200 type, NN-300 type), polyester (EP) belt (divided into It is EP-100 type, EP-150 type, EP-200 type, EP-300 type), large inclination

 (corrugated rib) conveyor belt, skirt partition belt, endless belt, pattern belt (due to different materials and conveying Different inclination

 angles require different pattern shapes and heights. Commonly used pattern conveyor belt varieties such as: herringbone pattern conveyor

belt, eight-shaped pattern conveyor belt, herringbone pattern conveyor belt, U-shaped pattern conveyor belt, cylindrical pattern conveyor belt,

Pit pattern conveyor belt, etc., or design according to user requirements). Waterstop, PVC whole core flame retardant belt, etc.; and can provide

various special properties (flame retardant conveyor belt, heat resistant conveyor belt, acid resistant conveyor belt, alkali resistant conveyor belt,

cold resistant conveyor belt, high temperature resistant conveyor belt and food conveying Belt) Conveyor belt.

Conveyor belt maintenance instructions

1. The conveyor belt should be kept clean during transportation and storage, avoid direct sunlight or rain and snow, prevent contact with acid,

alkali, oil, organic solvents and other substances, and be 1 meter away from the heating device.

2. During storage, the temperature in the warehouse should be kept between -18-40°C, and the relative humidity should be kept between 50-80%.

3. During the storage period, the product must be placed in a roll and not folded. During the storage period, it should be turned over every quarter.

4. Conveyor belts of different types and specifications are not suitable to be connected together, and the joints should preferably be glued.

5. The type, structure and number of layers of the conveyor belt should be selected reasonably according to the conditions of use.

6. The running speed of the conveyor belt should not be greater than 2.5 m/s. For materials with large lumps and abrasion, a fixed-force type

unloading device should be used, and a low speed should be used as much as possible.

7. The relationship between the diameter of the transmission roller of the conveyor and the cloth layer of the conveyor belt, the matching of the

transmission roller and the reversing roller, and the requirements for the bracket angle should be selected reasonably according to the design

requirements of the conveyor.

8. The feeding position should conform to the running direction of the tape. In order to reduce the impact of the material on the tape when the

material is falling, a chute should be used to reduce the material falling distance; the tape receiving section should shorten the distance between

the rollers and adopt the buffer roller to prevent leakage. Material and belt side should use soft and moderate baffle plate to prevent the baffle

plate from being too hard and scratching the belt surface of the conveyor belt.

9. The following items should be paid attention to during the use of the conveyor belt:

① Avoid the rollers being covered by the material and cause the rotation failure, prevent the leakage of the material between the card and the roller

 and the tape, pay attention to the lubrication of the movable part, but not oil the conveyor belt.

② Avoid starting with load;

③ If the tape deviation occurs, corrective measures should be taken in time;

④ The local damage of the tape should be repaired in time to avoid expansion;

⑤ Prevent the tape from being blocked by the frame, pillars or block materials, and prevent it from breaking and tearing.
